StarTech.com 3-Port USB-C Multi-Monitor Adapter, USB Type-C to 3x DisplayPort 1.4 MST Hub, Triple 4K 60Hz DP Laptop Display Extender / Splitter, HDR, Extra-Long Built-In Cable - Windows Only
StarTech.com 3-Port USB-C Multi-Monitor Adapter, USB Type-C to 3x DisplayPort 1.4 MST Hub, Triple 4K 60Hz DP Laptop Display Extender / Splitter, HDR, Extra-Long Built-In Cable - Windows Only is backordered and will ship as soon as it is back in stock.
StarTech.com 3-Port USB-C Multi-Monitor Adapter, USB Type-C to 3x D...
Create a high-performance triple-display workstation by connecting a USB Type-C™ device to three independent DisplayPort™ monitors
This USB-C to DisplayPort MST Hub enables a connection to three DisplayPort monitors, using a DisplayPort Alternate Mode (DP Alt Mode) capable USB-C enabled host device.
IT Pro Performance
This adapter features a unique video signal booster which amplifies the signal and ensures reliable performance, even with lower quality cables. The amplifier also increases the max. supported DP cable length compared to other brands.
Multi-tasking Made Easy
This USB-C to DisplayPort video splitter allows you to configure your displays in extended or duplicated mode. Connecting three independent 4K 60Hz displays creates high-performance workstations. This empowers increased multi-tasking across your organization, resulting in increased productivity.
Host Connection
Output 1 Resolution
Output 2 Resolution
Output 3 Resolution
DisplayPort 1.4 with DSC
4K 60Hz
4K 60Hz
4K 60Hz
DisplayPort 1.4
4K 60Hz
4K 30Hz
4K 30Hz
DisplayPort 1.2
4K 30Hz
4K 30Hz
1080p 60Hz
4K at 60Hz and HDR
Multi-Stream Transport (MST) technology combines multiple video signals into a single output signal/stream. This MST Hub separates the single input stream into three independent signals, one for each DisplayPort enabled display. Support for High Dynamic Range (HDR) offers increased contrast, brightness, colors, and greater luminosity.
Hassle-Free Setup
Windows devices that support DP Alt Mode over USB-C feature native support for MST. This USB-C to DisplayPort hub is compatible with Thunderbolt 3/4, and USB4 enabled Windows devices. Plug-and-play installation, with no drivers or software required. The 12in (30cm) attached cable provides options for flexible installation configurations, reducing the amount of strain on ports and connectors. Additionally, this triple-monitor splitter is bus-powered, meaning no external power is required.
This product is backed for 3-years, including free lifetime 24/5 multi-lingual technical assistance.
The StarTech.com Advantage
| Performance | |
|---|---|
| Data transfer rate (max) | 32.4 Gbit/s |
| Chipset | Synaptics VMM5330 |
| Audio output channels | 2.0 channels |
| Refresh rate at maximum resolution | 60 Hz |
| Maximum resolution | 4096 x 2160 pixels |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 3 |
| Number of displays supported | 3 |
| High Dynamic Range (HDR) supported | Yes |
| DisplayPort output | Yes |
| HDMI output | No |
| DVI output | No |
| USB connector form factor | Straight |
| USB connector gender | Male |
| USB connector type | USB Type-C |
| Design | |
|---|---|
| Integrated USB cable | Yes |
| Product colour | Grey |
| System requirements | |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64 |
| Mac compatibility | No |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 0 - 85% |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
|---|---|
| Package weight | 92.4 g |
| Package height | 30 mm |
| Package depth | 170 mm |
| Package width | 142 mm |
| USB cable length | 0.3 m |
| Weight | 52 g |
| Height | 14 mm |
| Depth | 300 mm |
| Width | 105 mm |
| Technical details | |
|---|---|
| Compliance certificates | CE, RoHS |
| Logistics data | |
|---|---|
| Products per master (outer) case | 70 pc(s) |
| Master (outer) case width | 473 mm |
| Master (outer) case length | 331 mm |
| Master (outer) case height | 440 mm |
-
