Always-on, space-saving solution with extreme-narrow bezels
See an immersive and dependable viewing experience, 24/7 with Samsung’s VHB-E series. The display’s slim depth and 700 nit brightness ensures highly visible images and legible messages in a wide range of locations from shopping malls to lobbies, meeting rooms, control rooms and more.
Transform any space with high impact visuals
The slender design and 70.4mm cabinet depth provide flexibility for installation and an extreme-narrow 1.74mm bezel-to-bezel width creates a seamless picture opening endless possibilities for designing a captivating visual experience.
View content from any angle
Wide viewing angles mean content is easily visible even if viewers aren’t standing directly in front of the display. Audiences can get clear details and vivid colors regardless of where the screen is located.
Vibrant images in any light
Non-glare panels evenly distribute light across the screen to maintain vibrant and accurate content. Combined with a high contrast ratio and 24/7 operation, visuals are vivid and eye-catching any time of the day or night — regardless of ambient light.
Image enhancement
Samsung’s powerful picture enhancement technology ensures all content is vibrant and clear. With Picture Enhancer mode, color saturation and contrast are improved by adjusting the gamma curve. Using Black Equalizer mode, dark images are lightened, making details easier to see.
Comprehensive calibration to fit your needs
Multi-step factory tuning provides uniform brightness and color. Users can also fine-tune advanced settings with free powerful Color Expert Pro software. For quick and simple calibration, Color Expert Pro Mobile enables white balance adjustments for displays up to 5x5 using a mobile camera.
Advanced presentation, simplified operation
Utilizing daisy chain design through DisplayPort 1.2 or HDMI ports enables the display to present UHD content on multiple screens without an external graphic card. Samsung's UHD Signage Player Box streamlines functionality by combining the media player and content management software.
Industry standard certified
The VHB-E series is EMC class B compliant, meeting strict standards of electromagnetic wave emission, while IP5x certification protects the display against dust and other conditions. The display packaging also passed a rigorous 2-step, ISTA-certified test to minimize possible damage during delivery.
| Display | |
|---|---|
| Operating hours (hours/days) | 24/7 |
| Colour gamut | 72% |
| Haze rate | 28% |
| Vertical scan range | 47 - 63 Hz |
| Horizontal scan range | 57.3 - 70 kHz |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Response time | 0.008 s |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 140000:1 |
| Display brightness | 700 cd/m² |
| Pixel pitch | 0.63 x 0.63 mm |
| Panel type | IPS |
| HD type | Full HD |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 139.7 cm (55") |
| Display technology | LCD |
| Design | |
|---|---|
| Panel colour | Black |
| Product colour | Black |
| International Protection (IP) code | IP5X |
| Panel mounting interface | 600 x 400 mm |
| VESA mounting | Yes |
| Bezel width (side) | 0.44 mm |
| Bezel width (bottom) | 1.3 mm |
| Orientation | Horizontal/Vertical |
| Placement supported | Indoor |
| Ports & interfaces | |
|---|---|
| HDCP | Yes |
| HDCP version | 2.2 |
| IR input ports quantity | 1 |
| Audio input | Yes |
| Audio output | Yes |
| USB version | 2.0 |
| USB ports quantity | 1 |
| RS-232C | Yes |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 input ports | 1 |
| RS-232 output ports | 1 |
| DisplayPort version | 1.2 |
| DisplayPorts quantity | 1 |
| DVI port | Yes |
| HDMI version | 2.0 |
| HDMI ports quantity | 2 |
| Power | |
|---|---|
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Energy consumption (SDR) per 1000 hours | 186 kWh |
| Energy efficiency class (SDR) | G |
| Power consumption (typical) | 250 W |
| General | |
|---|---|
| Product family | VHB-E |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Sustainability | |
|---|---|
| Certification | FCC (USA) Part 15, Subpart B Class B CE (Europe) : EN 55032:2015+A11:2020 / EN 55035:2017+A11:2020 / EN IEC 61000-3-2:2019 / EN 61000-3-3:2013+A1:2019 VCCI (Japan) : VCCI-CISPR32 : 2015 KC (Korea) : KS C 9832 / KS C 9835 RCM (Australia/ Newzealand) : AS/NZS CISPR32:2015 CCC (China) : GB/T 9254-2008, GB 17625.1-2012 BSMI (Taiwan) : CNS 13438 |
| Weight & dimensions | |
|---|---|
| Weight | 19.5 kg |
| Height | 683 mm |
| Depth | 70.4 mm |
| Width | 1212.2 mm |
| Packaging data | |
|---|---|
| Package weight | 27.1 kg |
| Package height | 844 mm |
| Package depth | 257 mm |
| Package width | 1398 mm |
-
