APC AP7822B power distribution unit (PDU) 16 AC outlet(s) 2U Black

£961.99 £970.99
Excl VAT £801.66

Key Details:
  • Single-phase Metered 2U Black
  • 16 AC outlet(s) C13 coupler, C19 coupler
  • 7680 W

APC  |  SKU: AP7822B  |  Condition: Brand New  |  Barcode: 0731304331520

Description
NetShelter Metered Rack PDU, 2U, 1PH, 7.4kW 230V 32A, x12 C13 and x4 C19 outlets, IEC 309 cord

APC Metered Rack PDUs offer resilient power distribution and actively measure, display, and log amperage to support real-time monitoring and historical reporting. This PDU remote monitoring and user-defined alarms to help prevent circuit overloads that can cause accidental power loss to critical equipment. The historical reporting enables users to optimize energy use and plan for capacity with confidence. This PDU can operate at up to 60 degrees Celsius and can be accessed, configured, and managed remotely via EcoStruxure IT, Web, SNMP and Command Line Interface. Power is supplied to the PDU at 200-230 volts via IEC 309 plug with a 3.6m (11 ft) cord while power comes out at 230 volts through (36) IEC 320 C13 and (6) IEC 320 C19 outlets. As a Green Premium product, this unit comes with a verified product environment profile, including carbon footprint, scope 3 emissions and end of life instructions.

Design
On/off switch Yes
Product colour Black
Mounting Horizontal/Vertical
Rack capacity 2U
Type Single-phase
PDU types Metered
Ports & interfaces
Output connections 12 x C134 x C19
Input connection type IEC 309 32A 2P+E
AC outlet types C13 coupler, C19 coupler
Power plug IEC309
AC outlets quantity 16 AC outlet(s)
Features
Certification C-tick, CE, FCC 15 A, GOST, ICES-003, IRAM, MIC, VDE, VCCI
Cable length 3.66 m
LED indicators Yes
Management features
Monitoring Current, Power, Voltage
Power
Power protection features Overload
Maximum power 7680 W
Maximum total current draw per phase 32 A
Maximum input current per phase 32 A
Load capacity 7680 VA
Maximum current 32 A
AC input frequency 50 - 60 Hz
Nominal input voltage 208-230 V
Weight & dimensions
Weight 3.36 kg
Dimensions (WxDxH) 444 x 112 x 88 mm
Packaging data
Package weight 5.41 kg
Package dimensions (WxDxH) 508 x 368 x 140 mm
Operational conditions
Operating relative humidity (H-H) 5 - 95%
Storage relative humidity (H-H) 5 - 95%
Storage temperature (T-T) -25 - 65 °C
Operating temperature (T-T) -5 - 45 °C
Technical details
Compliance certificates RoHS

Specifications
  • Grade
    Brand New
  • Part Number
    AP7822B

Grading Guide

Brand New – This product is Brand New and in it’s original
packaging.

New - Open Box - This product is unused but the box has been opened.

New – No Box – This product is unused but doesn’t come with
the original box/packaging.

Refurbished – This product has been refurbished by ourselves
or by the manufacturer.

Excellent Used – This item is used, tested and fully working
but in like new condition. It may come with it’s original packaging or not,
please check the product description.

Good Used – This item is used, tested and fully working but
will show signs of cosmetic wear and tear. It may come with it’s original packaging
or not, please check the product description.

Parts – This item is sold just for parts, meaning it is
unworking or unable to serve it’s purpose. It may come with it’s original packaging
or not, please check the product description.

Warranty

Brand New Products: All our Brand New products come with Manufaturer warranty. These can vary in length and it's important to check with the manufaturer of the product what warranty they provide and what is covered.

Used Products: All our used products come with 1 years warranty provided by us and some products may have manufaturer warranty.

Refurbished Products: With our refurbished products, we offer a free 3-month warranty which covers all software and hardware issues, that have not been influenced by the customer. There is also Manufactured Refurbished products which they will specify how long their warranty is.

Custom Gaming PCs: All our Custom PCs by default come with 3 years warranty. This includes parts and labour. You can also upgrade to 5 years warranty. Our warranty includes all hardware issues relating to the machine. If there is any faults, we will attempt to solve this remotely and if needed get the PC collected and back to base for repair.

Read more - Warranty Information

PDFs/Manuals
For extra information please see the manufaturers website
