HPE Aruba Networking Networking Instant On Switch 24p Gigabit CL4 PoE 2p SFP 195W 1830

HPE  |  SKU: JL813A  |  Condition: Brand New  |  Barcode: nan
£262.99
£248.99 Save £14.00 £262.99
£207.49 excluding VAT @20%
iFrame
Networking Instant On Switch 24p Gigabit CL4 PoE 2p SFP 195W 1830

HPE Networking Instant On Switch 1830 series provides an easy to use and affordable wired solution for networks supporting IT, mobile, and cloud applications. This affordable and easy-to-deploy smart-managed switch series is ideal for small businesses looking for cost-effective wired infrastructure to keep up with evolving network demands. These entry-level, smart-managed switches offer Layer 2 switching capabilities, Gigabit connectivity, along with flexible management modes - all at an affordable price point. With a flexible management dashboard, Power over Ethernet (PoE) options, and energy-efficient features, these switches deliver a solid business network for SMBs with limited budgets.

What is new supporting point:
Cost-effective PoE support: With half of the ports capable of supporting PoE, these switches are ideal for the most cost-efficient environments.
Two and four dedicated 1G SFP fiber ports on 24- and 48-port models respectively to eliminate traffic bottlenecks across your network.
HPE Networking Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely.
Option to manage your switches through local web GUI.
Compact and fan-less 8-port PoE/ non-PoE models and 24-port non-PoE model for acoustically sensitive environments.
Smart-managed Layer 2 Ethernet switch series ready to deploy in 8, 24-, and 48-port for non-PoE and PoE models.

Management features
Switch type Managed
Switch layer L2
Quality of Service (QoS) support Yes
Cloud-managed Yes
Web-based management Yes
System event log Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
SFP module slots quantity 2
Network
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support No
Port mirroring Yes
Full duplex Yes
Auto-sensing Yes
Auto MDI/MDI-X Yes
Spanning tree protocol Yes
Link aggregation Yes
Flow control support Yes
VLAN support Yes
Data transmission
MAC address table 16000 entries
Switching capacity 52 Gbit/s
Throughput 38.68 Mpps
Latency (10-100 Mbps) 5.2 µs
Latency (1 Gbps) 2.8 µs
Jumbo frames support Yes
Jumbo frames 9216
Packet buffer memory 1.5 MB
Security
DHCP features DHCP client
IGMP snooping Yes
SSH/SSL support Yes
Design
Rack mounting Yes
Form factor 1U
Performance
Built-in processor Yes
Processor model ARM Cortex-A9
Processor frequency 800 MHz
Memory type RDRAM
Internal memory 512 MB
Flash memory 256 MB
General
Product family Aruba Networking
Power
Power source AC
Power supply included Yes
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Power consumption note Maximum: 100-127V: 244.6W 200-220V: 237.2W; Idle: 100-127V: 14.5W 200-220V: 13.4W
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Total Power over Ethernet (PoE) budget 195 W
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 15 - 95%
Storage relative humidity (H-H) 15 - 95%
Weight & dimensions
Width 253 mm
Depth 443 mm
Height 43.9 mm
Weight 3.47 kg
Logistics data
Harmonized System (HS) code 85176990
Other features
Performance management HPE Networking Instant On Cloud; Web browser; SNMP Manager
Memory and processor ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5 MB
Weight (imperial) 3.47 kg (7.65 lbs)
I/O ports 24 RJ-45 10/100/1000 Class 4 PoE ports, 2 SFP 1GbE ports
Dimensions (W x D x H) (imperial) 253 x 443 x 43.9 mm (9.96 x 17.4 x 1.73")
