Lindy 12m USB 2.0 Active Extension Pro Hub

LINDY  |  SKU: 42783  |  Condition: Brand New  |  Barcode: 4002888427838
$66.00
$55.00 excluding VAT @20%
iFrame
12m USB 2.0 Active Extension Pro Hub

The Lindy USB Active Extension Hub Pro is a high performance hub with active cable that allows access to four USB 2.0 peripherals over long distances. With support for data transfer speeds of up to 480Mbps this extension cable is perfect for transferring data volumes quickly and reliably.

This 12m extension hub can be used standalone or as part of the Lindy USB 2.0 Active Extension System Pro. This system is a modular solution that can combine multiple USB Active Extension Pro cables and a USB 2.0 Active Extension Pro hub to distribute USB signals to up to 4 devices at up to 60m.

The 8m and 12m cable and the 8m and 12m hub feature a single active repeater module to boost the USB signal. The 30m cable uses two repeaters. A fully deployed extension system is limited to a maximum of 60m and 4 repeater modules. Any combination of cables and a single hub can be connected providing the 60m / 4 repeater limit is not exceeded. The extension hub must always be the last segment of the extension system.

This hub features industry-proven active technology and locking connectors to ensure full signal integrity in the most demanding environments.

Ports & interfaces
Ports quantity 4
USB 2.0 ports quantity 4
Card reader integrated No
DC-in jack Yes
Features
Data transfer rate 480 Mbit/s
Housing material Plastic
Product colour Black
AWG wire size 26/20
Cable diameter 5 mm
Cable length 12 m
Conductor material Tinned copper
Bend radius (min) 2.6 cm
Plug and Play Yes
Nominal attenuation (0.064 MHz, -0.08 dB) (0.256MHz, -0.11 dB) (0.512MHz, -0.13 dB) (0.772 MHz, -0.15 dB) (1 MHz, -0.2 dB) (4 MHz, -0.39 dB) (8 MHz, -0.57 dB) (12 MHz, -0.76 dB) (24 MHz, -0.95 dB) (48 MHz, -1.35dB) (96 MHz, -1.9 dB) (200 MHz, -3.2 dB) (400 MHz, -5.8 dB)
Power
USB powered Yes
Power note 3.5/1.35mm DC Connector
System requirements
Compatible operating systems Win ME, 2000, XP, Vista
Mac OS
Linux
Weight & dimensions
Width 80 mm
Depth 40 mm
Height 16 mm
Weight 463 g
Connector 1 dimensions (WxDxH) 15 x 43 x 8 mm
Packaging data
Package width 65 mm
Package depth 235 mm
Package height 200 mm
Package type Box
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -20 - 60 °C
Logistics data
Products per master (outer) case 10 pc(s)
Harmonized System (HS) code 84719000
Technical details
Compliance certificates CE, Federal Communications Commission (FCC), REACH, RoHS, TAA
Proposition 65 Yes
Other features
Interface USB 2.0/1.1
Connector(s) 1x USB-A M, 4x USB-A FM
Mac compatibility Yes
