Description
Description
Flow Luxury
Multi-directional vent design, featuring extensive air intakes at the bottom, power supply chamber and lower sides, along with top vents and large-area mesh at the front, creating a dedicated Antec Flux airflow channel.
Air intake via the PSU chamber maximizes heat dissipation while enhancing the intake effect for the graphics card.
Air intake via the front mesh provides smooth venting channel throughout the case.
Front panel is crafted with a combination of metal mesh and wood (birch) to create a high-quality texture with different materials, integrating seamlessly into your home design.
In addition to the standard PSU mount orientation,a 90-degree rotated option powered by the included extension cable is available. Plug in the cable connector from the right side, routing has never been easier. Support 180mm long PSU.
Left side of PSU chamber is detachable, making it easy to install the power supply.
Intuitive hardware temperature display design with 4 different modes:
- GPU & CPU On
- GPU & CPU Off
- Only CPU On
- Only GPU On
The Antec iUnity provides instant data on PC specs, loads, and usage.
Mount the fans/radiators on the cooling bracket first and install the cooling bracket back to the case.
When fans (2 available) are installed on the case bottom, remove the top shroud bracket to maximize the airflow, fulfilling the optimal vertical cooling scheme.
Vertically adjustable to 5 positions to fit the huge top AIO.
Can only accommodate Top 420mm + Front 360mm radiator, or Front 420mm + Top 360mm radiator at the same time.
Fully-open PCI slot covers can be removed to install the graphics card vertically.
For easy cleaning and strong dust prevention.
Description
Specification
- Form Factor: E-ATX
- #Hide#Small Form Factor: No
- Power Supply Wattage: No PSU
- Motherboard Support: "E-ATX up to 285mm, ATX, Micro ATX, Mini ITX"
- #Hide#Window(s): Yes (Window)
-
Connectors / Controls: 1 x USB 10Gbps Type-C
2 x USB 3.0
Headphone/Mic Combo Jack
Temp. Display Switch
Power Button
Reset Button -
Drive Bays: 4/4 x 3.5""/2.5""
2 x 2.5"" - Expansion Slots: 8 Expansion Slots
-
Cooling System: Included:
Front: 3 x 140mm Tranquil PWM fans
PSU Shroud: 2 x 120mm P12R PWM reverse fans
Rear: 1 x 140mm Tranquil PWM fan
Built-in ARGB & PWM fan control hub in sync with M/B
Fan Mounts:
Front: 3 x 120 / 3 x 140 mm
Top: 3 x 120 / 3 x 140 mm
PSU Shroud: 3 x 120 mm
Bottom: 2 x 120 / 2 x 140 mm
Rear: 1 x 120 / 1 x 140 mm
-
.:
Radiator Options:
Front: Up to 420 mm
Top: Up to 420 mm
PSU Shroud: Up to 360 mm
Bottom: Up to 240 mm
Rear: Up to 140 mm - Colour: White
-
Material: Steel + Plastic + Wood
4mm Tempered Glass Side Panel -
Compatibility: GPU max length:
455 mm
CPU cooler max height:
190 mm
PSU max length:
(Include cable) 180/300mm (with HDD)
(Include cable) 470mm (without HDD)
(Not Include cable) 180mm (Side Mount) -
Weight/Dimensions: 13.6 kg
(DxWxH) 530 x 245 x 545 mm -
Additional Features: Vertical Cooling
Horizontal Cooling
Innovative iShift PSU 90° Mount
Left side of PSU chamber is detachable
CPU/GPU Dual Temperature Display
Antec iUnity software
Removable Top Cooling Bracket
Removable Cooling Bracket on Top of PSU Shroud
Removable Front Cooling Bracket
Modular Hard Drive Cage
Bottom full-size pull-out dust filter
See Overview for more details - Package Weight: 16.6500 kg
- Warranty: 2 Years
