TP-Link Archer AX1800 Dual-Band Wi-Fi 6 VDSL/ADSL Modem Router
Key Details:
- Super VDSL – The Latest Super VDSL (VDSL2 Profile 35b) tech delivers internet speeds of up to 350Mbps, while G.vector and RNC technology ensure advanced data transmission stability
- Next-Gen Gigabit Wi-Fi 6 Speed - 1201 Mbps on 5 GHz and 574 Mbps on 2.4 GHz band ensure smoother streaming and faster downloads
- 2×2 MU-MIMO – Simultaneously transfers data to multiple devices for 4x faster performance
- VoIP Support - Support multiple VoIP accounts and various call features to surpass traditional landlines
- TP-Link Tether App – Easily access and manage your network, including remote control and automatic updates, using any iOS or Android mobile device
- Versatile Connectivity - Fully compatible with VDSL2/ADSL2+/ADSL2/ADSL standards, support Fiber and Cable connection through Ethernet port, as well as 3G/4G internet services through USB port
Description
Description
Stay Fast with Wi-Fi 6
AX1800 Dual-Band Wi-Fi 6
VDSL/ADSL Modem Router
Wi-Fi 6 Upgrades Incedible Speed
The Archer VX1800v features Super VDSL (VDSL2 Profile 35b), the latest generation of DSL technology. Downstream is increased by up to 350 Mbps, 3.5× faster than its VDSL2 predecessor. Compatibility with the leading ISPs provides ideal IP-based connections for any home. The integrated DSL port also supports all standard DSL connections.
Versatile Connectivity
Archer VX1800v is compatible with Super VDSL (VDSL2 Profile 35b), Ethernet access, and 3G/4G USB modems. Its Gigabit LAN/WAN port accepts connections from cable or fiber modems, and the USB 2.0 port supports 3G/4G dongles for a solid main or backup internet connection.
Gigabit Wired Connections and More
The USB port can be used to share files, music, and videos within your network at high speeds.
Equipped with a high-performance analog telephone system. Connecting external storage through the USB port can also realize the voice message function, without worrying about missing calls or deleting messages.
Plug your PCs, smart TVs, and game consoles into one of the three Gigabit Ethernet LAN ports for reliable wired connections of your broadband speed up to 1 Gbps.
Flexibly Create Whole Home Mesh WiFi
If you have any dead zones at home, just add another Easymesh-Compatible router/range extender to further form your whole home multi-gigabit mesh WiFi. No more searching for a stable connection.
Easy Setup and Use
Set up the Archer VX1800v in minutes thanks to its intuitive web interface and the powerful Tether app. Manage network settings, including Parental Controls and Access Control, from any Android or iOS device. Tether also provides Automatic Firmware Updates to always give your network the latest performance and security.
WPA3 Security
More secure encryption in Wi-Fi password safety and enhanced protection against brute-force attacks combine to safeguard your home Wi-Fi.
Parental Controls
Manage when and how your children's devices can access the internet.
Guest Network
Provides separate access for guests while securing the home network.
Quality of Service
Choose devices or activities you want to prioritize on your network with QoS in just a few taps.
| WAN connection | |
|---|---|
| WAN connection type | RJ-11/RJ-45 |
| 3G/4G USB modem compatibility | No |
| SIM card slot | No |
| DSL WAN | Yes |
| Ethernet WAN | Yes |
| Wireless LAN features | |
|---|---|
| WLAN data transfer rate (second band) | 1201 Mbit/s |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 1800 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Network | |
|---|---|
| VPN support | OpenVPN, PPTP VPN, IPSec VPN |
| VPN tunnels quantity | 10 |
| Number of guest networks (2.4 GHz) | 1 |
| Number of guest networks (5 GHz) | 1 |
| Static route | Yes |
| Dynamic DNS (DDNS) | Yes |
| Automatic channel selection | Yes |
| Port forwarding | Yes |
| Port triggering | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| DSL features | |
|---|---|
| VDSL2 | Yes |
| ADSL2+ | Yes |
| ADSL2 | Yes |
| ADSL | Yes |
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| RJ-11 ports quantity | 2 |
| USB 2.0 ports quantity | 1 |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 4 |
| Management features | |
|---|---|
| MU-MIMO technology | Yes |
| MIMO | Yes |
| WPS push button | Yes |
| Reset button | Yes |
| Web-based management | Yes |
| Security | |
|---|---|
| DMZ support | Yes |
| Parental control | Yes |
| Access Control List (ACL) | Yes |
| Security algorithms | WPA-Enterprise, WPA-PSK, WPA-Personal, WPA2-Enterprise, WPA2-PSK, WPA2-Personal, WPA3 |
| Protocols | |
|---|---|
| Universal Plug and Play (UPnP) | Yes |
| DHCP server | Yes |
| DHCP client | Yes |
| Design | |
|---|---|
| LED indicators | LAN, Power, WAN |
| Wall mountable | Yes |
| Product colour | Black |
| Product type | Tabletop router |
| General | |
|---|---|
| Product family | Archer |
| Sustainability | |
|---|---|
| Sustainability compliance | Yes |
| Packaging content | |
|---|---|
| Quick start guide | Yes |
| AC adapter included | Yes |
| Cables included | LAN (RJ-45), Phone (RJ-11) |
| Antenna | |
|---|---|
| Antennas quantity | 4 |
| Antenna design | External |
| Power | |
|---|---|
| Power source type | DC |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 60 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Weight & dimensions | |
|---|---|
| Width | 260.2 mm |
| Depth | 135 mm |
| Height | 41.6 mm |
| Packaging data | |
|---|---|
| Number of products included | 1 pc(s) |
| Package type | Box |
| Technical details | |
|---|---|
| Compliance certificates | CE, RoHS |
