j5create JCD542-N USB-C® Dual HDMI™ Docking Station, includes 2x HDMI ports and 4x USB ports, Grey & Black

J5CREATE  |  SKU: JCD542-N  |  Condition: Brand New  |  Código de barras: 4712795086041

MORE INFO

£82.99
£81.99 Save £1.00 £82.99
£68.33 excluding VAT @20%
iFrame
JCD542 USB-C® Dual HDMI Docking Station, includes 2x HDMI ports and 4x USB ports, Grey & Black

This dual display docking station adds dual HDMI™ monitors, with resolution support up to 4K (3840 x 2160) on one display and up to 2K (2048 x1152) or 1080p on the other display. You can also use your laptop screen for three displays in total, making it easy to access multiple applications at once.

This USB™ 3.0 docking station comes equipped with all the connections you need including three USB™ 3.0 ports, a RJ45 Gigabit Ethernet port, memory card reader/writer, combo audio jack, and a USB-C® port supporting up to 100W Power Delivery. It also includes a security lock slot to protect against theft, making it perfect for use in business organizations. With its slim and heat-dissipating design along with the double-sided cable storage compartment, this USB-C® dock ensures an easy connection regardless of your USB-C® port’s location and can easily fit into any workspace environment.

Ports & interfaces
USB Type-C DisplayPort Alternate Mode Yes
Combo headphone/mic port Yes
HDMI ports quantity 2
USB Power Delivery revision 3.0
USB Power Delivery up to 100 W
USB Power Delivery Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3
Host interface USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Network
Ethernet LAN data rates 10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports 1
Performance
Country of origin Taiwan
Housing material Aluminium
Hub interfaces 3.5mm, HDMI, RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Number of displays supported 2
Maximum refresh rate 30 Hz
HD type 4K Ultra HD
Compatible memory cards MicroSD (TransFlash), SD
Card reader integrated Yes
Product colour Black, Grey
Power
Power consumption (typical) 4.5 W
Output voltage 20 V
Output current 0.9 A
Power supply type USB
Software
Mac operating systems supported Mac OS X 10.11 El Capitan
Windows operating systems supported Windows 10
Operational conditions
Storage temperature (T-T) -10 - 65 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Weight 307 g
Height 22 mm
Depth 350.2 mm
Width 82.5 mm
Packaging data
Package weight 405 g
Package height 28 mm
Package depth 358 mm
Package width 88.3 mm
Quantity per pack 1 pc(s)
Packaging content
Manual Yes
Cables included USB Type-C
Packaging content 1 x JCD542 USB-C® Dual HDMI™ Docking Station, 1 x Quick Installation Guide (QIG)
Quick start guide Yes
Technical details
Warranty period 2 year(s)
Other features
Cable length 0.45 m
Maximum operating temperature 40 °C
