Lindy 1m Cat.6A U/UTP LSZH Ultra Slim Network Cable, Grey

LINDY  |  SKU: 47582  |  Condition: Brand New  |  Código de barras: 4002888475822
£24.99
£20.83 excluding VAT @20%
iFrame
1m Cat.6A U/UTP LSZH Ultra Slim Network Cable, Grey

Cat.6A U/UTP Ultra slim network cable with support for bandwidth up to 500MHz and features a snagless design with gold plated contacts for ethernet standards up to 10GBase-T.
Cat 6A cable, for operating frequencies up to 500MHz, unshielded with single twisted pair (U/UTP). Designed as ultra slim cable for use in environments with restricted or limited installation space. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag.
The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.
The very flexible and thin cable construction allows the cables to be installed in restricted or limited spaces such as server rooms or network hubs.
Available lengths: 0.3m, 1m, 1.5m, 2m, 3m, 5m.

Features
Cable length 1 m
Cable standard Cat6a
Cable shielding U/UTP (UTP)
Product colour Grey
Connector 1 RJ-45
Connector 2 RJ-45
Connector 2 form factor Straight
Connector 1 form factor Straight
Connector 2 gender Male
Connector 1 gender Male
Connector contacts plating Nickel/Gold
Connector shielding Yes
Connector shield material Aluminium
Jacket material Low smoke zero halogen (LSZH)
Conductor material Copper
Cable fire class Eca
AWG wire size 28
Frequency 500 MHz
Bend radius (min) 6 cm
Nominal attenuation 49.3dB/100m @ 500MHz
Certification RoHS, REACH, California Proposition 65
Operational conditions
Operating temperature (T-T) -10 - 60 °C
Storage temperature (T-T) -10 - 40 °C
Weight & dimensions
Width 11 mm
Depth 28 mm
Height 6 mm
Outer diameter 3.6 mm
Connector 2 dimensions (WxDxH) 11 x 28 x 6 mm
Connector 1 dimensions (WxDxH) 11 x 28 x 6 mm
Packaging data
Package width 15 mm
Package depth 133 mm
Package height 194 mm
Package type Polybag
Technical details
Shielding type Braiding
Compliance certificates REACH, RoHS
Proposition 65 Yes
Sustainability compliance Yes
Logistics data
Products per master (outer) case 240 pc(s)
Other features
Connector(s) RJ45 Male to RJ45 Male
Cable diameter 3.6 mm
