StarTech.com Dual Rail Rackmount KVM Console HD 1080p - Single Port DVI/VGA KVM w/17" LCD Monitor for Server Rack - Fully Featured 1U LCD KVM Drawer w/Cables - USB Support - 44230 MTBF
StarTech.com Dual Rail Rackmount KVM Console HD 1080p - Single Port DVI/VGA KVM w/17" LCD Monitor for Server Rack - Fully Featured 1U LCD KVM Drawer w/Cables - USB Support - 44230 MTBF est en rupture de stock et sera expédié dès qu’il sera de retour en stock.
StarTech.com Dual Rail Rackmount KVM Console HD 1080p - Single Port...
1080p Display | 17 Inch | 1U | DVI & VGA Interface | Cables Included
Providing centralized control of your single PC or dozens of servers, this dual rail rackmount KVM console (QWERTY keyboard) also gives you easy access to and visibility of your system while it’s mounted in a server rack or cabinet.
Dual Rail Design
The dual rail KVM console design maximizes space in your datacenter’s rack cabinets by allowing the LCD monitor and the keyboard/mouse to move separately from each other. You can tuck the keyboard away while the display stays active, allowing you to conveniently monitor your computer through closed glass or mesh rack cabinet doors.
High Definition LCD Monitor
The 1080p KVM console is 17.3” and LED back-lit, for low power consumption. It supports high definition resolutions up to 1920x1080 providing sharper video performance.
Digital & Analog Support
Whether you are running a multi-port KVM with an analog display or a single port KVM with a high definition display, this DVI/ VGA KVM console can support both signals.
Simple Setup
This KVM console comes with everything you need to set up:
✔ 1 Audio Cable
✔ 1 Set of KVM Cables (USB/VGA)
✔ 2 Rear Mounting Brackets
✔ M5 Cage Nuts and Screws
Once your KVM console is mounted to your rack, you can use the USB port on the front to easily connect any USB compatible peripheral such as a fingerprint scanner or mousethumb drive.
StarTech.com offers a wide selection of KVM consoles to help you access your systems more efficiently without the expense and clutter of extra peripherals. This dual rail KVM console is backed by a 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
| Display | |
|---|---|
| Supported resolutions | 1024x5761152x6481280x7201366x761600x9001920x1080 |
| On Screen Display (OSD) | No |
| Response time | 8 ms |
| Display brightness | 250 cd/m² |
| Contrast ratio (typical) | 650:1 |
| Viewing angle, horizontal | 140° |
| Viewing angle, vertical | 120° |
| Pixel pitch | 0.199 x 0.199 mm |
| Aspect ratio | 16:9 |
| Display type | LCD |
| Display number of colours | 262144 colours |
| Display | TFT LCD |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 43.9 cm (17.3") |
| Technical details | |
|---|---|
| Mean time between failures (MTBF) | 44230 h |
| Product colour | Black |
| Operating relative humidity (H-H) | 0 - 80% |
| Rack mounting | Yes |
| LED indicators | Yes |
| Compliance certificates | RoHS |
| Material | Steel |
| Rack capacity | 1U |
| Ports & interfaces | |
|---|---|
| USB 2.0 Type-A ports quantity | 2 |
| USB 2.0 Type-B ports quantity | 1 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI/VGA |
| DVI input ports | 1 |
| DVI output ports | 1 |
| DVI connector type | DVI-D |
| 3.5 mm (1/8-inch) in | Yes |
| 3.5 mm (1/8-inch) out | Yes |
| Keyboard | |
|---|---|
| Hot keys | Yes |
| Certificates | |
|---|---|
| Certification | CE, FCC, UL, REACH |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Power | |
|---|---|
| Input current | 1 A |
| AC adapter input voltage | 100 - 240 V |
| Power consumption (typical) | 19.4 W |
| Weight & dimensions | |
|---|---|
| Mounting depth (max) | 100 cm |
| Mounting depth (min) | 65 cm |
| Weight | 13.6 kg |
| Depth | 727 mm |
| Height | 44 mm |
| Width | 480 mm |
| Packaging data | |
|---|---|
| Package height | 133 mm |
| Package depth | 840 mm |
| Package width | 680 mm |
| Package weight | 18.9 kg |
| Packaging content | |
|---|---|
| Quick installation guide | Yes |
| Cage nuts included | Yes |
| Number of cage nuts | 8 |
| Included power plug types | ANZ, EU, JP, NA, UK |
| Mounting brackets included | Yes |
| Screws included | Yes |
| Number of screws | 8 |
| Cables included | Audio (3.5mm), KVM |
| Logistics data | |
|---|---|
| Products per master (outer) case | 1 pc(s) |
| Master (outer) case height | 133 mm |
| Master (outer) case length | 840 mm |
| Master (outer) case width | 680 mm |
-
