Vertiv Liebert GXT5 Double Online Conversion UPS -5000VA/5000W| 230V| With Rackmount Kit and Intellislot RDU101 Communication Card| GXT5-5000IRT5UXLN

VERTIV  |  SKU: GXT5-5000IRT5UXLN  |  Condition: Brand New  |  Código de barras: 767041026634
£4,295.99
£3,579.99 excluding VAT @20%
iFrame
5U Rack/Tower | 7 Minute Stand-by | 230 V AC Input | 200 V AC, 208 V AC, 220 V AC Output | 6 x IEC 60320 C13, 2 x IEC 60320 C19 Receptacle(s) | Single Phase | Pure Sine Wave | Serial Port | SNMP/Webcard | 5-year Warranty (3-year Standard Warranty + 2-year Extended Warranty)

The Vertiv Liebert GXT5 uninterruptible power supply (UPS) protects critical equipment against outages and every type of power disturbance. This 5kVA/5kW online double conversion UPS offers continuous power conditioning in centralized and edge locations. With unity power factor (1.0), it allows more connected loads saving space and costs. This tower/rack mount UPS has a built-in Vertiv RDU101 communications card for remote monitoring to help you make more informed decisions and faster event resolution. With the free Vertiv Power Insight software, you can consolidate your view of up to 100 distributed UPS units providing simple notification of status and events in a single pane of glass. This 230V in/ 230 out single phase UPS has scalable runtime options with matching external battery cabinets to give extra runtime during an outage to support critical equipment. This battery backup is ENERGY STAR 2.0 certified and comes with an intuitive gravity sensing full-color LCD display. It comes with a 5-year warranty (3-year factory warranty plus 2-year extended warranty). This promotion is subject to the Distributor’s product availability and is only available while product stocks last. Vertiv reserves the right to provide a 1-month notice to terminate the offer. This offer is not available in conjunction with any other offer/discount.

Features
UPS topology Double-conversion (Online)
Output power capacity 5 kVA
Output power 5000 W
Waveform Pure sine
Input operation voltage (min) 176 V
Input operation voltage (max) 288 V
Input frequency 40 - 70 Hz
Output operation voltage (min) 230 V
Output operation voltage (max) 240 V
Output frequency 50 Hz
Output voltage regulation 3%
Response time 0 ms
Number of input phases 1
Number of output phases 1
Single-phase input voltage supported 200,208,220,230,240 V
Efficiency 94%
Efficiency (On-line mode) 94%
Power factor 1
Input power factor 0.99
Output power factor 1
Emergency Power Off (EPO) Yes
Overload capacity (5 minute) 125%
Overload capacity (1 minute) 150%
Noise level 55 dB
Power protection features Overload
Audible alarm(s) Yes
Ports & interfaces
AC outlet types C13 coupler, C19 coupler, IEC 320, Terminal
Power plug Terminal
AC outlets quantity 8 AC outlet(s)
USB port Yes
RS-232 ports 1
Serial ports quantity 1
Battery
Battery technology Sealed Lead Acid (VRLA)
Battery capacity 9 Ah
Battery voltage 12 V
Number of batteries supported 16
Typical backup time at full load 7 min
Typical backup time at half load 18.5 min
Battery recharge time(90%) 5 h
Hot-swap battery Yes
Design
Form factor Rackmount/Tower
Product colour Black
Rack capacity 5U
Cooling type Active
Display type LCD
International Protection (IP) code IP20
Certification CE, EMI/EMC/C-Tick EMC, ESD
General
Product family Liebert
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -15 - 40 °C
Operating relative humidity (H-H) 0 - 95%
Storage relative humidity (H-H) 0 - 95%
Operating altitude 0 - 3000 m
Safety regulation & standards
Safety IEC62040-1:2008
Technical details
Compliance certificates RoHS
Weight & dimensions
Width 430 mm
Depth 630 mm
Height 217 mm
Weight 70.8 kg
Package width 646 mm
Package depth 816 mm
Package height 520 mm
Package weight 89 kg
Logistics data
Harmonized System (HS) code 85078000
Other features
Battery type VRLA
Output voltage 230 V
