D-Link 5-Port Gigabit Smart Managed Switch

D-LINK  |  SKU: DGS-1100-05V2/B  |  Condition: Brand New  |  Código de barras: 0790069453281

MORE INFO

£53.99
£44.99 excluding VAT @20%
iFrame
5 x 10/100/1000 Mbps RJ-45, 10 Gbps, 7.44 Mpps, 2K MAC, 100.5 x 82 x 28 mm, UK

Advanced Security Features
The DGS-1100 series’ web user interface gives administrators an easy way to manage Layer 2 features, such as VLANs, Spanning Tree Protocol (STP), and link aggregation (desktop models utilize Static Trunk). With powerful security features including IGMP snooping, Static MAC, and Storm Control, these smart managed switches are a versatile solution for deployments that require easy to configure functionality without added complexities.

Simplify Network Management
D-Link’s free Network Assistant (DNA) utility displays all your connected devices and makes first-time configuration a breeze. The free D-View 7 Network Management System comes with a license for 25 nodes and 2 probes and full access to the management tools.

Easy Troubleshooting
The DGS-1100 Series features Loopback Detection and Cable Diagnostics to help network administrators find and solve network problems quickly and easily.
Loopback Detection detects loops created by a specific port and automatically shuts down the affected port. The Cable Diagnostics feature is designed for network administrators to quickly examine the quality of the copper cables, recognize the cable type, and detect cable errors.

Green Technology
D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. The desktop models in the series utilize a fanless design, for silent and energy-efficient operation. All models are also IEEE 802.3az-compliant and feature Link Status detection.

Management features
Web-based management Yes
Cloud-managed Yes
Quality of Service (QoS) support Yes
Switch layer L2
Switch type Managed
Ports & interfaces
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 5
Network
Auto MDI/MDI-X Yes
Copper ethernet cabling technology 1000BASE-T
10G support No
Data transmission
Packet buffer memory 1 MB
Jumbo frames 9216
Jumbo frames support Yes
Forwarding rate 7.4 Mpps
Switching capacity 10 Gbit/s
MAC address table 2000 entries
Design
Number of fans 0 fan(s)
Reset button Yes
Product colour Black
Rack mounting No
Performance
Fanless Yes
Noise level 0 dB
Power
Power consumption (max) 3.42 W
Input current 1 A
DC input voltage 5 V
AC input frequency 50/60 Hz
AC input voltage 100 - 240 V
Power source AC
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating altitude 0 - 2000 m
Storage relative humidity (H-H) 0 - 95%
Operating relative humidity (H-H) 0 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Weight 230 g
Height 82 mm
Depth 28 mm
Width 100.5 mm
Logistics data
Harmonized System (HS) code 85176990
