Flexible, powerful and optimized
Designed for flexibility and high performance for today's demanding modern workloads and applications.
| Management features | |
|---|---|
| Configuring Location Settings (CLI) | Yes |
| Quality of Service (QoS) support | Yes |
| Switch layer | L2/L3 |
| Switch type | Managed |
| Ports & interfaces | |
|---|---|
| QSFP+ module slots quantity | 3 |
| SFP+ module slots quantity | 12 |
| SFP module slots quantity | 1 |
| Network | |
|---|---|
| VLAN support | Yes |
| 10G support | Yes |
| Networking standards | IEEE 802.3 |
| Data transmission | |
|---|---|
| Latency (10-100 Mbps) | 800 µs |
| Throughput | 630 Mpps |
| Switching capacity | 840 Gbit/s |
| Multicast features | |
|---|---|
| Multicast support | Yes |
| Protocols | |
|---|---|
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Design | |
|---|---|
| Safety | UL/CSA 60950-L Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition Including all National Deviations and Group Differences, EN 60825-1 Safety of Laser Products Part1: Equipment Classification Requirements and User’s Guide, EN 60825-2 Safety of Laser Products Part 2: Safety of Optical Fibre Communications Systems, FDA Regulation 21 CFR 1040.10 and 1040.11 |
| Number of fans | 3 fan(s) |
| Ventilation system | Front-to-back airflow |
| Product colour | Black |
| Form factor | 1U |
| Stackable | Yes |
| Rack mounting | Yes |
| General | |
|---|---|
| Product family | S-Series |
| Power | |
|---|---|
| Power consumption (max) | 180 W |
| Power consumption (typical) | 90 W |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Number of power supply units | 2 |
| Power supply included | Yes |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | No |
| Operational conditions | |
|---|---|
| Heat dissipation | 614 BTU/h |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 5 - 85% |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating temperature (T-T) | 5 - 40 °C |
| Weight & dimensions | |
|---|---|
| Weight | 3.76 kg |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85176990 |
