ASUS NUC 13 90AR00C1-M000L0 PC/workstation barebone UCFF Black i7-1360P
Powered by Autify Digital Ltd
ASUS NUC 13 90AR00C1-M000L0 PC/workstation barebone UCFF Black i7-1360P est en rupture de stock et sera expédié dès qu’il sera de retour en stock.
ASUS NUC 13 90AR00C1-M000L0 PC/workstation barebone UCFF Black i7-1...
Business Driver. Space Saver.
NUC 13 Pro Mini PCs, Kits, and Boards offer the combination of size, performance, and reliability you need to drive modern business.
It all starts with 13th Gen Intel Core processors that deliver outsized performance in a 4x4 form factor, with up to 14 processor cores (6P+8E) and up to 64GB dual-channel DDR4 memory. Select SKUs also come with Intel vPro® Enterprise, which provides comprehensive security, enterprise-grade stability, and hardware-based remote management.
The NUC Pro Software Suite (NPSS) helps to ensure digital signage applications keep running during any unexpected system failures. Businesses also benefit from advanced features including power control, hardware alarm clock, hardware KVM, boot redirection, beyond firewall support, cloud-based manageability, remote PC remedy, and unattended system control.
To provide an eco-friendly foundation for businesses, NUC 13 Pro Mini PCs and Kits are upgradable, reparable, and reusable. Every system is qualified for 24x7 operation.
| Processor | |
|---|---|
| Processor cache | 18 MB |
| Processor boost frequency | 5 GHz |
| Efficient-core boost frequency | 3.7 GHz |
| Performance-core boost frequency | 5 GHz |
| Efficient cores | 8 |
| Performance cores | 4 |
| Processor threads | 16 |
| Processor cores | 12 |
| Processor model | i7-1360P |
| Processor generation | 13th gen Intel® Core™ i7 |
| Processor family | Intel® Core™ i7 |
| Processor manufacturer | Intel |
| Built-in processor | Yes |
| Memory | |
|---|---|
| ECC | No |
| Maximum internal memory | 64 GB |
| Memory voltage | 1.2 V |
| Supported memory clock speeds | 3200 MHz |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Dual-channel |
| Number of memory slots | 2 |
| Memory slots type | SO-DIMM |
| Storage | |
|---|---|
| Number of storage drives supported | 3 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Storage drive sizes supported | M.2,2.5 |
| Supported storage drive types | SSD |
| Graphics | |
|---|---|
| Number of displays supported | 4 |
| On-board graphics card model | Intel Iris Xe Graphics |
| Graphics card family | Intel |
| On-board graphics card | Yes |
| Audio | |
|---|---|
| Built-in speaker(s) | No |
| Network | |
|---|---|
| LAN controller | Intel I226-V |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| Thunderbolt 4 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Serial port via internal header | No |
| Combo headphone/mic port | Yes |
| HDMI version | 2.1 |
| HDMI ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 2.0 ports quantity | 1 |
| Expansion slots | |
|---|---|
| PCI Express slots version | 4.0 |
| Design | |
|---|---|
| Product type | Mini PC barebone |
| VESA mounting | Yes |
| LED indicators | Yes |
| On/off switch | Yes |
| Cooling type | Active |
| Product colour | Black |
| Chassis type | UCFF |
| Performance | |
|---|---|
| Motherboard form factor | UCFF |
| Processor special features | |
|---|---|
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel ME Firmware Version | 16.1 |
| Intel® Optane™ Memory Ready | No |
| Intel® Platform Trust Technology (Intel® PTT) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| General | |
|---|---|
| Product family | NUC 13 |
| Product series | Pro Kit |
| Software | |
|---|---|
| Linux operating systems supported | Yes |
| Windows operating systems supported | Windows 11 Home, Windows 11 Pro, Windows 10 IoT Enterprise |
| Power | |
|---|---|
| Power supply type | External AC adapter |
| Weight & dimensions | |
|---|---|
| Height | 54 mm |
| Depth | 112 mm |
| Width | 117 mm |
-
